Edwards STP-H200C rebuilt turbo molecular pump
Edwards STP-H200C rebuilt turbo molecular pump
| Model | STP-H200C |
|---|---|
| Manufacturer | Edwards |
| Unit Price | $6,000 |
| Type | Turbo Pump |
| Pumping Speed (N2) | 220 l/s |
| Ultimate pressure ( 60Hz ) | 1.33 x 10¯7 mbar |
| Vibration ( peak to peak ) | < 0.01 µm |
| Bearing Type | Magnetic Levitation |
| Rotational Speed | 36,000 rpm |
| Inlet Connection | ISO100K / ISO100F |
| Outlet Connection | NW25 |
| External Cooling | Air cooled / Water cooled |
| Weight | 20 Kg |
| Installation orientation | Any |
| Condition | Refurbished |
